Warner Electric 6001-448-006 On and Off Control

Model No – CBC-801-2
Input Voltage – 220/240 VAC 50/60 Hz
Output Voltage – 90 VDC 1.25 A max.
Part No – 6001-448-006

CBC-801 Series Controls
CBC801_controlMulti-Unit Capacity The CBC-801 is a basic on-off power supply that provides full voltage to a 90 volt clutch or brake and is activated by an external switch. The CBC-801 is a plug-in power supply, which is used with an octal socket (purchased separately). The CBC-801 will operate two units separately, or simultaneously.





Click on the links below to see Drawings and Specs:

Warner Electric Clutch and Brake Controls PDF
